ASE40401101000 Adaptér otáčok VAS 6296A

The universal engine speed adapter VAS 6296A serves to quickly and easily measure the engine speed on petrol and diesel engines in conjunction with emissions testing station VAS 6300/3, emissions testing station V.A.G 1700/1800, ignition tester V.A.G 1767 and diesel tester V.A.G 1743 and is included in the items supplied with emissions testing stations VAS 7310A and VAS 7320A.
This engine speed adapter VAS 6296A also replaces the previous engine speed adapter VAS 5087A. Fundamentally, the adapter works by evaluating two signals:
- the engine's structure-borne noise signal
- the air-borne noise signal
The system records both signals at the same time. The ideal signal is automatically used for engine speed evaluation.
Selecting the number of cylinders is not necessary.
Items supplied
Basic equipment
Mains unit, external
Combined sensor
Connecting cable for clamp sender input
Means of attachment
Operating instructions on CD (various languages)
Transport and storage case
Technical data
Changeover of operating mode from car/van to motorcycle with 4 or 2 stroke engine
Diesel engine speed: 400…6000 rpm
Petrol engine speed: 400…8000 rpm
Speed search range:
Idle speed: 400…1200 rpm
High speed: 1700…6000 rpm
4 stroke motorcycle speed:
Idle speed: 600…1800 rpm
High speed: 2200…8000 rpm
2 stroke motorcycle speed:
Idle speed: 900…2200 rpm
High speed: 1800...8000 rpm
Signal input: Combined sensor for structure-borne noise and air-borne noise
Signal output: Charge signal (clamp sender):
Simulation of electric clamp sender signal (1100 pC)
Digital pulse: 5 V TTL-compatible
Inductive pulse:
Simulation of ignition signal for inductive trigger clamps, approx. 150 mA amplitude
Current supply:12 V direct current, 350 mA
USB interface for PC connection (DSS SW from AVL DiTEST required) Operating temperatures:
Evaluation unit: 0…+50° C, no direct sunlight
Sensor cable: +0…+65° C
(Magnetic base: -20…125° C)
Storage temperature: -20…+60° C
Air humidity: < 90 %, non-condensing
Protection rating: VAS 6296A: IP31
Combined sensor: IP54
Dimensions: 227 × 184 × 48 mm (length × width × height)
Weight: VAS 6296A: 0.8 kg
Combined sensor: 0.38 kg
Conforms to 89/336/EEC directive for electromagnetic compatibility
Compliant by meeting standards
EN 50081-1 General standard for emitted interference 1992
EN 50082-1 General standard for resistance to interference 1992
Disposal:
This product is a high quality electrical and electronic device that must not be disposed of through the domestic waste system.
------------------------------
ASE 404 011 01 000
------------------------------

Dimensions of the package (l X w X h)
380 / 280 / 180
